Chapter 7: Technical Specifications 67
Video (Main) Out Level: 1V p-p
Source Impedance: 75 ohms
(VITC In) Format: SMPTE 90-bit, drop frame/non-drop frame
Line Range: 10 to 40 (all-line mode), 10 to 22 (single-line mode)
(VITC Out) Format: SMPTE 90-bit, drop frame/non-drop frame
Line Range: Two lines, 10 to 20
Video (Ref) In Format: NTSC or PAL composite video
Level: 1V p-p
Termination: 100K ohms
Video (Ref) Out Level: 1V p-p
Termination: 100K ohms
Description: Passive loop-thru of Video Ref in
AES/EBU In Level: 5 V p-p at 110 ohms (pin 2 hot)
Connector: 3-pin XLR female per IEC 268-12
AES/EBU Out Level: 5 V p-p at 110 ohms (pin 2 hot)
Connector: 3-pin XLR male per IEC 268-12
Rear Panel Connectors
Connector Specifications
