Avtech AVH306 User Manual

CONNECTION
6
2.3 Manual Connection Setup
To manually assign a channel to connect to the IP camera, select a corresponding “PROTOCOL” from the drop
down list first, click “URI” to enter the address of the camera, and enter its port number. There are four protocol
types available in the drop down list as follows: “AVTECH”, “ONVIF”, “RTSP OVER HTTP”, and “RTSP OVER
UDP”. If you are using AVTECH IP cameras, please select “AVTECH”; otherwise, choose the protocols your
cameras support.
ADVANCED CONFIG
CONNECTION CHANNEL PROTOCOL URI PORT
PATH CONFIG
CAMERA
CH1 AVTECH ://ip_office.ddns.eagleeyes.tw :80 / SETUP
DETECTION
CH2 ONVIF ://10.1.1.14 :88 / SETUP
ALERT
CH3 RTSP OVER HTTP ://10.1.1.30 :88 / SETUP
NETWORK
CH4 RTSP OVER UDP ://10.1.1.12 :88 / SETUP
DISPLAY
CH5 AVTECH ://10.1.1.16 :88 / SETUP
RECORD
CH6 AVTECH ://10.1.1.13 :88 / SETUP
NOTIFY
EXIT

Avtech AVH306 Specifications

General

Product color	Black
Channels quantity	6 channels
Video compression formats	H.264, M-JPEG, MPEG4
Compatible operating systems	Windows 7, Vista & XP
Playback resolutions supported	1920 x 1080
USB 2.0 ports quantity	2
Ethernet interface type	Gigabit Ethernet
Supported network protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	10 - 40 °C
Power requirements	DC 19V / 2.1A

Weight and Dimensions

Dimensions (WxDxH)	370 x 264 x 55 mm
