Avtech AVH306 User Manual

MAIN MENU
30
6.4.4 ALERT
ADVANCED CONFIG
CONNECTION
EXT. ALERT ON
CAMERA
INT. BUZZER OFF
DETECTION
KEY BUZZER ON
ALERT
VLOSS BUZZER ON
NETWORK
MOTION BUZZER ON
DISPLAY
ALARM BUZZER ON
RECORD
HDD BUZZER ON
NOTIFY
ALARM DURATION (SEC) 5
HDD NEARLY FULL (GB) 5
EXIT
1) EXT. ALERT
Select to enable or disable the sound when any external alarm is triggered (ON / OFF).
2) INT. BUZZER
Select to enable or disable the sound (ON / OFF) for all internal buzzers: KEY BUZZER, VLOSS BUZZER,
MOTION BUZZER, ALARM BUZZER, and HDD BUZZER.
Note: When this item is set to “OFF”, item 3) to item 7) will be disabled even though they are set to ON.
3) KEY BUZZER
Select to enable or disable the sound when pressing the buttons on the front panel (ON / OFF).
4) VLOSS BUZZER
Select to enable or disable the sound when video loss happened (ON / OFF).
5) MOTION BUZZER
Select to enable or disable the sound when any motion alarm is triggered (ON / OFF).
6) ALARM BUZZER
Select to enable or disable the sound when any internal alarm is triggered (ON / OFF).
7) HDD BUZZER
Select to enable or disable the sound (ON / OFF) when the HDD remaining capacity reaches to the value set
in “HDD NEARLY FULL (GB)”.
8) ALARM DURATION (SEC)
Select the duration time for alarm buzzer in second (5 / 10 / 20 / 40).
9) HDD NEARLY FULL (GB)
If HDD BUZZER is enabled, select the duration time for buzzer notifications when the hard disk available
capacity is 5/10/15/20 GB left.

Avtech AVH306 Specifications

General

Product color	Black
Channels quantity	6 channels
Video compression formats	H.264, M-JPEG, MPEG4
Compatible operating systems	Windows 7, Vista & XP
Playback resolutions supported	1920 x 1080
USB 2.0 ports quantity	2
Ethernet interface type	Gigabit Ethernet
Supported network protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	10 - 40 °C
Power requirements	DC 19V / 2.1A

Weight and Dimensions

Dimensions (WxDxH)	370 x 264 x 55 mm
