MAIN MENU
27
5) SEARCH
Click “START” to start search and play the video data immediately.
6.3.3 HDD INFO
You can check the information of the connected hard disk(s) in the NVR.
EVENT INFORMATION
QUICK SEARCH
NUMBER MODEL
o
C
EVENT SEARCH
EVENT TIME COMMENT
HDD INFO
KEY UNLOCK 2011/NOV/19 15:49:07
EVENT LOG
VIDEO LOSS 2011/NOV/19 15:32:05 04
POWER ON 2011/NOV/19 15:32:02
PREV NEXT CLEAN
EXIT
6.4 ADVANCED CONFIG
6.4.1 CONNECTION
To manually assign a channel to connect to the IP camera, select a corresponding “PROTOCOL” from the drop
down list first, click “URI” to enter the address of the camera, and enter its port number. There are four protocol
types available in the drop down list as follows: “AVTECH”, “ONVIF”, “RTSP OVER HTTP”, and “RTSP OVER
UDP”. If you are using AVTECH IP cameras, please select “AVTECH”; otherwise, choose the protocols your
cameras support.
ADVANCED CONFIG
CONNECTION CHANNEL PROTOCOL URI PORT
PATH CONFIG
CAMERA
CH1 AVTECH ://ip_office.ddns.eagleeyes.tw :80 / SETUP
DETECTION
CH2 ONVIF ://10.1.1.14 :88 / SETUP
ALERT
CH3 RTSP OVER HTTP ://10.1.1.30 :88 / SETUP
NETWORK
CH4 RTSP OVER UDP ://10.1.1.12 :88 / SETUP
DISPLAY
CH5 AVTECH ://10.1.1.16 :88 / SETUP
RECORD
CH6 AVTECH ://10.1.1.13 :88 / SETUP
NOTIFY
EXIT
To Next Page
