USER INTERFACE
8
3.1.3 Quick Operation
For details, please refer to “5. QUICK OPERATION” at page 17.
Click to show the power off panel to either halt or reboot the system.
Click to show the channel switch panel and select the channel you want.
Switch to the channel you want first, and click
to enter the zoom-in mode. In this mode, click and drag the red frame on
the bottom left of the screen to move to the place you want to see.
Click to enter the PTZ mode and show the PTZ camera control panel.
Click to open the IP search window and check the current connection status of each channel.
3.1.4 Main Menu
For details, please refer to “6. MAIN MENU” at page 20.
QUICK START
Click to set the status display, image settings, and date & time.
SYSTEM
Click to set the system configurations.
EVENT INFORMATION
Click to enter the event search menu.
ADVANCED CONFIG
Click to set CONNECTION, CAMERA, DETECTION, ALERT, NETWORK, DISPLAY,
RECORD and NOTIFY.
SCHEDULE SETTING
Click to set record timer and event timer.
3.1.5 Playback Panel
Fast Forward Increase the speed for fast forward from 4X to 32X.
Fast Rewind Increase the speed for fast rewind from 4X to 32X.
/
Play / Pause
Click to play the latest recorded video clip immediately, and click again to pause.
In the pause mode, click
once to get one frame forward, and click to get one frame rewind.
Stop Click to stop the video playback.
Slow Playback Click once to get 1/4X speed playback, and click twice to get 1/8X speed playback.
/
Previous /
Next Hour
Click to jump to the next / previous time interval in an hour, for example, 11:00 ~ 12:00 or
14:00 ~ 15:00, and start playing the earliest event video clip recorded during this whole hour.
Quick Search Click to enter the quick search menu for specific record data search.
