Avtech AVH306 User Manual

FREQUENTLY-USED FUNCTIONS
16
4.8.1 Convert the file format to AVI
To convert the video file format to AVI, click “AVI” from the playback panel to start file conversion.
Note: The recorded audio (if any) will be removed when the file format is converted to AVI.
Note: If the backup video includes data for multiple channels, click to a specific channel for this
function to work properly.

Avtech AVH306 Specifications

General

Product color	Black
Channels quantity	6 channels
Video compression formats	H.264, M-JPEG, MPEG4
Compatible operating systems	Windows 7, Vista & XP
Playback resolutions supported	1920 x 1080
USB 2.0 ports quantity	2
Ethernet interface type	Gigabit Ethernet
Supported network protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	10 - 40 °C
Power requirements	DC 19V / 2.1A

Weight and Dimensions

Dimensions (WxDxH)	370 x 264 x 55 mm
