APPENDIX 6 RECORDING TIME TABLE
44
APPENDIX 5 SPECIFICATIONS
For Model 1
Hardware
Video Input
One LAN port
Up to 6 Channels with a hub
Video Output Full HD Output
Video Output Resolution 1920 x 1080
Audio Output YES
HDD Storage** Up to two 3TB HDDs
USB Ports
Two on the front panel:
one for video backup to USB flash drive, and
another for NVR control via a USB mouse
IR Remote Control YES
LAN port 1000Mbps
Ethernet
Internet port
10Mbps / 100Mbps
Software
Video Compression Format H.264 / MPEG4 / MJPEG
Recording Mode Manual / Event / Alarm / Schedule
Recording Throughput 50Hz IP camera Up to 150 @ 720P, 32 Mbps
60Hz IP camera Up to 180 @ 720P, 32 Mbps
Pre-alarm Recording YES
Quick Search Time / Motion / Alarm
Security Multiple user access levels with password
Remote Access
(1) Internet Explorer on Windows operating system
(2) EagleEyes on iPhone, iPad & Android mobile devices
(3) Our self-developed program, Video Viewer
General
Power Source (±10%) DC 19V / 2.1A
Operating Temperature
10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)** 370(W) × 55(H) × 264(D)
Minimum PC Browsing Requirements
Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD‧
256 MB ‧ RAM
AGP graphics card, Direct Draw, 32MB RAM‧
Windows ‧ 7, Vista & XP, DirectX 9.0 or later
Internet Explorer ‧ 7.x or later
Peripherals
(1) EoC converter
(2) High Resolution Display Extender
(3) Video Server
* Specifications are subject to change without notice.
** Dimensional tolerance: ±5mm

Avtech AVH306 Specifications

General

Product color	Black
Channels quantity	6 channels
Video compression formats	H.264, M-JPEG, MPEG4
Compatible operating systems	Windows 7, Vista & XP
Playback resolutions supported	1920 x 1080
USB 2.0 ports quantity	2
Ethernet interface type	Gigabit Ethernet
Supported network protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	10 - 40 °C
Power requirements	DC 19V / 2.1A

Weight and Dimensions

Dimensions (WxDxH)	370 x 264 x 55 mm
