QUICK OPERATION
19
To fix the camera IP address, or allow the NVR to assign an IP address to your IP camera, select “SETUP”, and
select “STATIC IP “ or DHCP” for “NETWORK TYPE”.
Click “APPLY” and “EXIT” to save your changes.
SETUP
NETWORK TYPE DHCP
IP 10.1.1.14
PORT 00080
USER NAME admin
PASSWORD *****
NETMASK 255.0.0.0
GATEWAY 10.1.1.10
PRIMARY DNS 168.95.1.1
APPLY EXIT
To connect to another IP camera, select the unused IP camera from the IP search list, and select “CONNECT”.
Select the channel you want to display the camera images, and click “SAVE” to start connection.
CONNECT
IP 10.1.1.14
PORT 88
CHANNEL CH5
USER NAME admin
PASSWORD *****
SAVE CANCEL

Other manuals for Avtech AVH306

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Avtech AVH306 and is the answer not in the manual?

Avtech AVH306 Specifications

General IconGeneral
Product colorBlack
Channels quantity6 channels
Video compression formatsH.264, M-JPEG, MPEG4
Compatible operating systemsWindows 7, Vista & XP
Playback resolutions supported1920 x 1080
USB 2.0 ports quantity2
Ethernet interface typeGigabit Ethernet
Supported network protocolsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
HDD interfaceSerial ATA
Maximum HDD capacity6000 GB
Operating temperature (T-T)10 - 40 °C
Power requirementsDC 19V / 2.1A
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)370 x 264 x 55 mm
