Specifications
13.11 System Clock
System clock internally 32kHz, 44.1kHz, 48kHz, 50ppm.
Frame clock out: BNC 75 Ohm TTL
Frame clock in: BNC 75 Ohm terminator switch, TTL 32kHz to 48kHz
13.12 Remotes
All channel remotes are isolated on relays and interfaced on 9 pin Sub-D connectors.
More info: isolated Photo MOS Relays, Ron-max 12ohm, Imax=200mA, 24Vmax
13.13 Dimensions and Weight
Desktop layout: Width=260mm Height=85mm Depth=370mm
19”rack in/output unit: Width= 485mm Height=88.5mmDepth=300mm
Notes: 0dBu=775 mV.
All measurements were made on an
Audio Precision system Two.
For more info on this and many other broadcast consoles contact your nearest dealer or AXEL
TECHNOLOGY.
Axel Technology S.r.l
Via Caduti di Sabiuno 6/F
40011 Anzola dell’Emilia
Phone: +39 051 736555
Fax: +39 051 736170
Website: http://www.axeltechnology.it
Mail to: support@axeltechnology.com
Axel Technology reserves the right to change these specs at any time, due to new product
improvements and new components.
Oxygen 4 Digital - from Axel Technology Phone +39 051736555, support@axeltechnology.com Page 61
