5. General scale view
ATA120÷ATA520 and ATZ120÷ATZ520 scale:
1 – pan
2 – pan support
(under pan)
3 – pan ring
(against blows)
4 – display LCD
5 – keys
6 – rotating legs
7 – water level
8 – draft shield
(option)
9 – draft shield cover
(option)
ATA1200÷ATA2200 and ATZ1200÷ATZ2200 scale:
1 – pan
2 – pan support
3 – information window
4 – display LCD
5 – keys
6 – rotating legs
7 – level
6
1
2
5
4
7
6
1
8
9
2
5
3
4
7
