Axis P3344 User Manual

AXIS P3344 Fixed Dome Network Camera
Technical Specifications
Technical Specifications
Function/group
Item
Specifications
Models
AXIS P3344
Image sensor
Progressive s can RGB CMOS 1/4'‘
Lens Varifocal with remote zoom and focus, IR corrected, megapixel r esolution
6mm: 2.5 – 6 mm, F1.4, DC-iris
Horizontal angle of view: 87° — 40°
Vertical angle of view: 54° — 24°
Diagonal angle of view: 102° — 46°
12 mm:3.3–12mm,F1.6,DC-iris
Horizontal angle of view: 70° — 20°
Vertical angle of view: 40° — 12°
Diagonal angle of view: 81° — 23°
Day and Night Automatically removable infrared-cut filter
Minimum
illumination
6mm:
Color: 0.3 lux, F1.4
B/W: 0.05 lux, F1.4
12 mm:
Color: 0.4 lux, F1.6
B/W: 0.06 lux, F1.6
Shutter time
1/25000 s to 1 /6 s
Camera
Camera angle
adjustment
Pan 360°, tilt 170°, rotation 340°
Video
compression
H.264 Baseline Profile (MPEG-4 Part 10/AVC)
Motion JPEG
Resolutions
1440x900 (1.3 MP) scaled resolution a vailable via VAPIX®
1280x800 (1 MP) to 160x90
Frame rate H.264 30 fps in all resolutions
Frame rate
Motion JPEG
30 fps in all resolutions
Video streaming
Multiple, individually configurable streams in H.264 and Motion JPEG
H.264andMotionJPEG:1streaminresolutionandframerateasspecified above. More
streams if identical or limited in frame rate or resolution
Controllable frame rate and bandwidth
VBR/CBR H.264
Pan/Tilt/Zoom
Digital PTZ, preset positions, guard tour
Video
Image settings
Compression, color, brightness, sharpness, contrast, white balance, exposure control,
exposure zones, backlight compensation, fine tuning of behavior at low light, wide
dynamic range — dynamic contrast
Rotation: 0°, 90°, 180°, 270°, including Corridor Format
TM
Mirroring of images
Text and image overlay
Privacy mask
53

Axis P3344 Specifications

General

Maximum resolution	1280 x 800 pixels
Pan range	0 - 360 °
Tilt angle range	0 - 170 °
Angle of rotation	340 °
Camera shutter speed	1/25000 - 1/6 s
Minimum illumination	0.4 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Focal length range	3.3 - 12 mm
Video motion detection	Yes
Power source type	PoE
I/O ports	RJ-45
Dimensions (WxDxH)	96 x 96 x 148 mm
Processor model	ARTPEC-3
Flash memory	128 MB
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS.
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	445 g
