AXIS Q1755/-E - System Options
Date & Time
Current Server Time - Displays the current date and time (24h clock). The time can be displayed in 12h clock format in the
overlay (see below).
New Server Time - Select your time zone from the drop-down list. If you want the server clock to automatically adjust for
daylight savings time, select the Automatically adjust for daylight saving time changes.
Note:
The time zone setting only applies when the device’s time is synchronized with an NTP server.
From the Time Mode section, select the preferred method to use for setting the time:
• Synchronize with computer time - sets the time from the clock on your computer.
• Synchronize with NTP Server - the camera will obtain the time from an NTP server.
• Set manually - this option allows you to manually set the time and date.
Note:
If using a host name for the NTP server, a DNS server must be configured under TCP/IP settings.
See Basic TCP/IP Settings, below.
Date & Time Format Used in Images - specify the formats for the date and time (12h or 24h) displayed in the video streams.
Use the predefined formats or use your own custom date and time formats. See File Naming & Date/Time Formats in the
online help
for information on how to create your own date and time formats.
Network
Basic TCP/IP Settings
AXIS Q1755/-E support both IP version 4 and IP version 6. Both versions may be enabled simultaneously, and at least one
version must always be enabled. When using IPv4, the IP address for the camera can be set automatically via DHCP, or a static
IP address can be set manually. If IPv6 is enabled, the network cameras receive an IP address according to the configuration in
the network router. There are also options for setting up notification of changes in the IP address, and for using the AXIS
Internet Dynamic DNS Service. For more information on setting the IP address, please see the online help.
Network Settings
Click the View button for an overview of the IP configuration of the network camera.
IPv4 Address Configuration
Check the Enable IPv4 box to enable IPv4.
Obtain IP address via DHCP - Dynamic Host Configuration Protocol (DHCP) is a protocol that lets network administrators
centrally manage and automate the assignment of IP addresses on a network. DHCP is enabled by default. Although a DHCP
server is mostly used to set an IP address dynamically, it is also possible to use it to set a static, known IP address for a
particular MAC address.
Note:
DHCP should only be enabled if your DHCP server can update a DNS server, which then allows you to access the net-
work camera by name (host name). If DHCP is enabled and you cannot access the unit, run AXIS IP Utility to search
the network for connected Axis products or reset the network camera to factory default settings and then perform the
installation again.

Axis Q1755 Specifications

General

Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/10000 - 1/2 s
Minimum illumination	2 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
Power source type	PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17.4 W
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	186 x 85 x 211.4 mm
Power requirements	20 - 24 V AC
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Processor model	ARTPEC-3
Flash memory	256 MB
Internal memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	985 g
