AXIS Q1755/-E - Technical Specifications
General performance considerations
When setting up your system, it is important to consider how various settings and situations will affect performance. Some
factors affect the amount of bandwidth (the bit rate) required, others can affect the frame rate, and some affect both. If it is
slow response in the UI, latency in images, too low FPS (contrary to settings), this will also affect the frame rate.
The following factors are among the most important to consider:
• High image resolutions and/or lower compression levels result in larger images. Bandwidth affected.
• Access by large numbers of Motion JPEG and/or unicast H.264 clients. Bandwidth affected.
• Simultaneous viewing of different streams (resolution, compression, etc.) by different clients. Frame rate and band-
width affected.
• Accessing both Motion JPEG and H.264 video streams simultaneously. Frame rate and bandwidth affected.
• Heavy usage of event settings affects the camera’s CPU load. Frame rate affected.
• Enabled motion detection. Frame rate and bandwidth affected.
• Heavy network utilization due to poor infrastructure. Bandwidth affected.
• Viewing on poorly performing client PC’s lowers perceived performance. Frame rate affected.
Dimensions
(HxWxD)
AXIS Q1755: 58 x 79 x 186 mm (2.3" x 3.1" x 7.3")
AXIS Q1755-E including sunshield: 87/120 x 140/161 x 404 mm
(3.4/4.7”
x 5.5/6.4” x 15.9”)
Weight AXIS Q1755: 1.0 kg (2.2 lb) excl. power supply
AXIS Q1755-E: 3.5 kg (7.7 lb.)
Included accessories Mounting and connector kits, Installation Guide, CD with installation tools,
recording software and User’s Manual, Windows decoder 1-user license
Video management
software
(not included)
• AXIS Camera Station - Video management software for viewing and recording
up to 50 cameras
• See www.axis.com/partner/adp_partners.htm for more software applications
via partners
• AXIS Q1755-E: wall mount bracket, sunshield, 5 m (16 ft.) Ethernet cable
Optional accessories • YP3040 PT Motor
• AXIS T8412 Installation Display
• AXIS T90A Illuminators
• AXIS Power over Ethernet Midspan 1-port, AXIS T8123 High PoE Midspan
1-Port
• AXIS Camera Station and video management software from Axis’ Application
Development Partners
• AXIS Q1755: Various housings
• AXIS Q1755-E: Mounting accessories
Function/group Item Specification

Axis Q1755 Specifications

General

Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/10000 - 1/2 s
Minimum illumination	2 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
Power source type	PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17.4 W
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	186 x 85 x 211.4 mm
Power requirements	20 - 24 V AC
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Processor model	ARTPEC-3
Flash memory	256 MB
Internal memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	985 g
