Axis Q1755 User Manual

57
AXIS Q1755/-E - Technical Specifications
System
Integration
Application
Programming
Interface
• Open API for software integration, including VAPIX® from Axis
Communications*, AXIS Media Control SDK*, event trigger data in video stream,
the ONVIF specification available at www.onvif.org
• Quality of Service (QoS) layer 3, DiffServ Model
• Embedded Linux operating system
*Available at www.axis.com
Intelligent Video Video motion detection, active tampering alarm, audio detection, Gatekeeper
Alarm triggers Video motion detection, active tampering alarm, audio detection, temperature
and external input
Alarm events • File upload via FTP, HTTP and email
• Notification via email, HTTP and TCP
• External output activation
Video buffer 96 MB pre- and post alarm
Video access from
web browser
• Camera live view
• Video recording to file (ASF)
• Customizable HTML pages
• Windows 7, Windows Vista, XP, 2000, 2003 server
• DirectX 9c or higher
• For other operating systems and browers see www.axis.com/techsup
General Casing AXIS Q1755: Metal (zink)
AXIS Q1755-E: IP66- and NEMA 4X-rated, IK10 impact-resistant aluminum
enclosure
Processors, memory • ARTPEC-3, 256 MB RAM, 128 MB Flash
• Battery backed-up real-time clock
Power • AXIS Q1755: 8 – 20 V DC max 11,2 W, 20 - 24 V AC max 17,4 VA or Power over
Ethernet IEEE 802.3af Class 3
• AXIS Q1755-E: Power over Ethernet IEEE 802.3af Class 3 or High Power over
Ethernet
Connectors • RJ-45 10BASE-T/100BASE-TX PoE, terminal block for power, I/O terminal block
for two configurable inputs/outputs
• 3.5 mm mic/line in, 3.5 mm line out
• RS485/RS422
• Video out: 3x RCA Y/Pb/Pr (HD), 1x RCA Composite (SD)
Local Storage SD/SDHC memory card slot (memory card not included)
Operating
conditions
• AXIS Q1755: 0 ºC to 45 ºC (32 ºF to 113 ºF) Humidity 20-80% RH
(non-condensing)
• AXIS Q1755-E: -40 ºC to 45 ºC (-40 ºF to 113 ºF) with High Power over
Ethernet, -30
ºC to 45 ºC (-22 ºF to 113 ºF) with Power over Ethernet IEEE
802.3af Class 3
Arctic Temperature Control enables camera start-up at temperatures as low as
-40
°C (-40 °F) with High PoE
Approvals • EN 55022 Class B
• EN 61000-3-2
• EN 61000-3-3
• EN 55024
• EN 61000-6-1
• EN 61000-6-2
• EN 60950-1
• FCC Part 15, Subpart B, Class B
• VCCI, Class B ITE
• C-tick AS/NZS CISPR 22
• ICES-003, Class B
• AXIS Q1755-E: IP66, NEMA 250 Type 4X, IK10
Function/group Item Specification

Axis Q1755 Specifications

General

Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/10000 - 1/2 s
Minimum illumination	2 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
Power source type	PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17.4 W
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	186 x 85 x 211.4 mm
Power requirements	20 - 24 V AC
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Processor model	ARTPEC-3
Flash memory	256 MB
Internal memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	985 g
