Axis Q1755 User Manual

56
AXIS Q1755/-E - Technical Specifications
Technical Specifications
Function/group Item Specification
Camera Models • AXIS Q1755 50 Hz/60 Hz
• AXIS Q1755-E 50 Hz/60 Hz
Image sensor 1/3" Progressive Scan CMOS 2 Megapixel
Lens • f 5.1 - 51 mm, F1.8 - 2.1
• Auto day/night IR filter, autofocus
• Near focus limit: 10mm (wide) or 800mm (tele)
• Angle of view, horizontal: 50° – 5.4°
• M37x0.75 mounting thread for optional lens adaptor
Minimum
illumination
Color: 2 lux at 30IRE, F1.8
B/W: 0.2 lux at 30IRE, F1.8
Shutter time 1/10000s to 1/2s
Zoom 10x optical and 12x digital, total 120x
Video Video compression • H.264 Baseline profile
• Motion JPEG
Resolutions • HDTV 1080i 1920x1080
• HDTV 720p 1280x720
Frame rate H.264 30/25 fps in all resolutions
Frame rate
Motion JPEG
30/25 fps in all resolutions
Video streaming • Multi-stream H.264 and Motion JPEG: simultaneous, individually configured
streams in max. resolution at 30/25 fps
• Controllable frame rate and bandwidth
• VBR/CBR H.264
• Max 10 simultaneous clients
Image settings • Compression, brightness, sharpness, white balance, exposure control, backlight
compensation, rotation
• Mirroring of images
• Text and image overlay
• Privacy mask
Audio Audio streaming Two-way, full duplex
Audio compression • AAC LC 8/16 kHz
• G.711 PCM 8 kHz
• G.726 ADPCM 8 kHz
• Configurable bit rate
Audio Input/Output External microphone or line input, line output
AXIS Q1755: Built-in microphone
Network Security Password protection, IP address filtering, HTTPS encryption*, IEEE 802.1X
network access control, digest authentication, user access log
*This product includes software developed by the Open SSL Project for use in the
Open SSL Tool kit (www.openssl.org)
Supported protocols IPv4/v6, HTTP, HTTPS, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP,
ICMP, DHCP, ARP, SOCKS, etc.
*This product includes software developed by the Open SSL Project for use in the
Open SSL Tool kit (www.openssl.org)

Axis Q1755 Specifications

General

Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/10000 - 1/2 s
Minimum illumination	2 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
Power source type	PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17.4 W
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	186 x 85 x 211.4 mm
Power requirements	20 - 24 V AC
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Processor model	ARTPEC-3
Flash memory	256 MB
Internal memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	985 g
