Axis Q1755 User Manual

55
AXIS Q1755/-E - Troubleshooting
For further assistance, please contact your reseller or see the support pages on the Axis website at www.axis.com/techsup
Browser freezes
Older browsers
Update your browser and Java to latest versions.
Problems uploading files
Limited space
There is only limited space available for the upload of your own files. Try deleting
existing files to free up space.
Motion Detection triggers unexpectedly
Changes in luminance
Motion detection is based on changes in luminance in the image. This means
that if there are sudden changes in the lighting, motion detection may be trig-
gered mistakenly. Lower the sensitivity setting to avoid problems with lumi-
nance.
No audio
Incorrect setup
Check the sound card in the PC. Ensure that the mute button is not pressed and
the volume settings are correct.
No audio or
very poor audio quality
Check that the correct Audio Input source is selected under Setup > Audio >
Source. Select Microphone for the internal microphone or for a connected exter-
nal microphone. Select Line for a connected line in source.
Audio volume too low/high
Volume settings incorrect
The volume of the microphone is either too high or too low. Change the volume
for the microphone in the toolbar on the Live View page.
Poor audio quality
CPU overloaded
Reduce the number of listeners and viewers and decrease the image resolution
and compression.
Unsynchronized audio and video
It is recommended that the camera's time setting is synchronized with an NTP
Server. This is enabled under System Options > Date & Time.
Distorted audio
Check that the correct Audio Input source is selected under Setup > Audio Set-
tings > Source. Select Microphone for the internal microphone or for a con-
nected external microphone. Select Line for a connected line in source.

Axis Q1755 Specifications

General

Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/10000 - 1/2 s
Minimum illumination	2 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
Power source type	PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17.4 W
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	186 x 85 x 211.4 mm
Power requirements	20 - 24 V AC
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Processor model	ARTPEC-3
Flash memory	256 MB
Internal memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	985 g
