Axis Q6032-E PTZ User Manual

AXIS Q6032-E PTZ Dome Network Camera
Technical Specifications
Technical Specifications
Function/group
Item
Specifications
Models
AXIS Q6032-E 60 Hz
AXIS Q6032-E 50 Hz
Image sensor
1/4” ExView HAD Progressive scan CCD
Lens f 3.3 – 119 mm
F1.4–4.2
Autofocus
Automatic day/night
Horizontal angle of view: 57.2° – 1.7°
Minimum
illumination
Color: 0.5 lux at 30 IRE
B/W: 0.008 lux at 30 IRE
Shutter time
1/30000 s to 0.5 s (60 Hz)
1/30000 s to 1.5 s (50 Hz)
Pan/Tilt/Zoom
E-flip
100 preset positions
Pan 360° endless, 0.05° – 450°/s
Tilt: 220°, 0.05° – 450°/s
36x optical zoom and 12x digital zoom, total 432x zoom
Camera
Pan/Tilt/Zoom
functionalities
Tour recording, guard tour, control queue
On-screen directio n al indicator
Video
compression
H.264 (MPEG-4 Part 10/AVC)
Motion JPEG
Resolutions
Extended D1 752x480 to 176x120 (60 Hz)
Extended D1 736x576 to 176x144 (50 Hz)
Frame rate H.264
Up to 30/25 fps (60/50 Hz) in all resolutions
Frame rate
Motion JPEG
Up to 30/25 fps (60/50 Hz) in all resolutions
Video streaming
Multiple, individually configurable streams in H.264 and M otion JPEG
Controllable frame rate and ba n dwidth
VBR/CBR H.264
Video
Image settings
Wide Dynamic Range (WDR
), Electronic Image Stabilization (EIS), manual shutter time,
compression, color, brightness, sharpness, white balance, exposure control, exposure
zones, backlight compensation, fine tuning of behavior at low light
Rotation: 0°,
180°
Text and image overlay
32 individual 3D privacy masks
Image fre
eze on PTZ
Security Password protection, IP address filtering, HTTPS encryption*, IEEE 802.1X network access
control*, digest authentication, user access log
*
This product includes software d eveloped by the Open SSL Project for use in the Open
SSL Toolkit (www.openssl.org)
Network
Supported
protocols
IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour,
UPnP
TM
, SNMPv1/v2c/v3(MIB-II), DN S, DynDNS, NTP, RTSP, RTP, TCP , UDP, IGMP, R TCP,
ICMP, DHCP, ARP, SOCKS, etc
*This product includes software developed b y the Open SSL Project for use in the Open
SSL Toolkit (www.openssl.org)
52
