Ayra Compar Kit FX1 - Spotlight DMX Functions

021 - 255: Stroboscope speed (slow -
fast)
23 Laser movement 000 - 099: Laser movement speed (fast
- slow)
100 - 109: No laser movement
(stationary)
110 - 209: Laser movement speed
(slow - fast)
210 - 255: Sound-controlled mode
24 LED main dimmer (Spotlight 1) 000 - 255: 0 - 100% intensity
25 Stroboscope and pulse effects (Spotlight 1) 000 - 007: Dimmer function on
008 - 015: Dimmer function off
016 - 131: Stroboscope speed (slow -
fast)
132 - 139: Dimmer function on
140 - 181: Slow off, fast on pulse effect
(slow - fast)
182 - 189: Dimmer function on
190 - 231: Fast off, slow on pulse effect
(slow - fast)
232 - 239: Dimmer function on
240 - 247: Random strobe effect
248 - 255: Dimmer function on
26 Dimmer red (Spotlight 1) 000 - 255: Dimmer red, 0 - 100%
intensity
27 Dimmer green (Spotlight 1) 000 - 255: Dimmer green, 0 - 100%
intensity
28 Dimmer blue (Spotlight 1) 000 - 255: Dimmer blue, 0 - 100%
intensity
29 Dimmer white (Spotlight 1) 000 - 255: Dimmer white, 0 - 100%
intensity
30 Colour selection (Spotlight 1) 000 - 005: No function
006 - 125: Fixed colours (various
colours)
126 - 189: Colour jumps (slow - fast)
190 - 253: Colour fades (slow - fast)
254 - 255: Colour selection via sound-
controlled mode
31 LED main dimmer (Spotlight 2) 000 - 255: 0 - 100% intensity
32 Stroboscope and pulse effects (Spotlight 2) 000 - 007: Dimmer function on
008 - 015: Dimmer function off
016 - 131: Stroboscope speed (slow -
fast)
132 - 139: Dimmer function on
140 - 181: Slow off, fast on pulse effect
(slow - fast)
182 - 189: Dimmer function on
190 - 231: Fast off, slow on pulse effect
(slow - fast)
232 - 239: Dimmer function on
240 - 247: Random strobe effect
248 - 255: Dimmer function on
33 Dimmer red (Spotlight 2) 000 - 255: Dimmer red (0 - 100%
intensity)
34 Dimmer green (Spotlight 2) 000 - 255: Dimmer green, 0 - 100%
intensity
