Ayra Compar Kit FX1 - Spotlight 2-4 DMX Functions

35 Dimmer blue (Spotlight 2) 000 - 255: Dimmer blue, 0 - 100%
intensity
36 Dimmer white (Spotlight 2) 000 - 255: Dimmer white, 0 - 100%
intensity
37 Colour selection (Spotlight 2) 000 - 005: No function
006 - 125: Fixed colours (various
colours)
126 - 189: Colour jumps (slow - fast)
190 - 253: Colour fades (slow - fast)
254 - 255: Colour selection via sound-
controlled mode
38 LED main dimmer (Spotlight 3) 000 - 255: 0 - 100% intensity
39 Stroboscope and pulse effects (Spotlight 3) 000 - 007: Dimmer function on
008 - 015: Dimmer function off
016 - 131: Stroboscope speed (slow -
fast)
132 - 139: Dimmer function on
140 - 181: Slow off, fast on pulse effect
(slow - fast)
182 - 189: Dimmer function on
190 - 231: Fast off, slow on pulse effect
(slow - fast)
232 - 239: Dimmer function on
240 - 247: Random strobe effect
248 - 255: Dimmer function on
40 Dimmer red (Spotlight 3) 000 - 255: Dimmer red (0 - 100%
intensity)
41 Dimmer green (Spotlight 3) 000 - 255: Dimmer green, 0 - 100%
intensity
42 Dimmer blue (Spotlight 3) 000 - 255: Dimmer blue, 0 - 100%
intensity
43 Dimmer white (Spotlight 3) 000 - 255: Dimmer white, 0 - 100%
intensity
44 Colour selection (Spotlight 3) 000 - 005: No function
006 - 125: Fixed colours (various
colours)
126 - 189: Colour jumps (slow - fast)
190 - 253: Colour fades (slow - fast)
254 - 255: Colour selection via sound-
controlled mode
45 LED main dimmer (Spotlight 4) 000 - 255: 0 - 100% intensity
46 Stroboscope and pulse effects (Spotlight 4) 000 - 007: Dimmer function on
008 - 015: Dimmer function off
016 - 131: Stroboscope speed (slow -
fast)
132 - 139: Dimmer function on
140 - 181: Slow off, fast on pulse effect
(slow - fast)
182 - 189: Dimmer function on
190 - 231: Fast off, slow on pulse effect
(slow - fast)
232 - 239: Dimmer function on
240 - 247: Random strobe effect
248 - 255: Dimmer function on
47 Dimmer red (Spotlight 4) 000 - 255: Dimmer red, 0 - 100%
intensity
