Number
3-wire system 4-6
5-wire system 4-7
A
Accessories
1-3
Alarm code 10-2
Application example 5-80
Application layer 7-6, 7-3
AT Derivative time adjust 5-26
AT Integral time adjust 5-26
AT Proportional Band adjust 5-26
AT start 5-29
AT Stop/Start 5-11
AT type 5-26
Auto tuning (AT) 5-26, 5-29
AUTO/MANUAL mode 5-10
Auxiliary relay 4-4
B
Bank selection display
2-3
Bank setup display 2-3
Basic configuration 2-1, 2-7
C
C01 PV input range type
5-1
C02 Temperature unit 5-3
C03 Cold junction compensation (T/C) 5-3
C04 Decimal point position 5-5
C05 PV range low limit 5-6
C06 PV range high limit 5-6
C07 SP low limit 5-42
C08 SP high limit 5-42
C09 PV square root extraction dropout 5-4
C10 RSP input range type
5-33
C11 RSP range low limit 5-34
C12 RSP range high limit 5-34
C14 Control action (Direct/Reverse) 5-15
C15 Output operation at PV alarm 5-15
C16 Output at PV alarm 5-15
C17 Output at READY (Heat) 5-15
C18 Output at READY (Cool) 5-15
C19 Output operation at changing Auto/Manual 5-16
C20 Preset manual value 5-16
C21 Initial output type (mode) of PID control 5-16
C22 Initial output of PID control
5-17
C23 PID Decimal point position 5-17
C24 Zone PID operation 5-23
C26 Heat/Cool control 5-15
C27 Heat/Cool 5-24
C28 Heat/Cool control dead zone 5-24
C29 Heat/Cool change point 5-24
C30 LSP system group 5-33, 5-43
C31 SP ramp type 5-33, 5-44
C32 SP ramp unit 5-38, 5-45
C33 STEP time unit 5-45
C34 STEP PV start 5-46
C35 STEP loop 5-47
C36 CT1 operation type 5-91
C37 CT1 output 5-91
C38 CT1 measurement wait time 5-91
C39 CT2 operation type 5-91
C40 CT2 output 5-91
C41 CT2 measurement wait time 5-91
C42 Control output 1 range 5-87
C43 Control output 1 type 5-87
C44 Control output 1 scaling low limit 5-88
C45 Control output 1 scaling high limit 5-88
C46 Control output 1 MV scalable bandwidth 5-89
C47 Control output 2 range 5-87
C48 Control output 2 type 5-87
C49 Control output 2 scaling low limit 5-88
C50 Control output 2 scaling high limit 5-88
C51 Control output 2 MV scalable bandwidth 5-89
C52 Auxiliary output range 5-87
C53 Auxiliary output type 5-87
C54 Auxiliary output scaling low limit 5-88
C55 Auxiliary output scaling high limit 5-88
C56 Auxiliary output MV scalable bandwidth 5-89
C57 Position proportional type 5-109
C58 Position proportional dead zone 5-111
C59 Motor long life mode 5-111
C60 Motor adjust 5-111
C61 Input with motor fully closed 5-115
C62 Input with motor fully open 5-115
C63 Motor full close-full open time 5-115
C64 Communication type 7-1
C65 Station address 7-1
C66 Transmission speed 7-1
C67 Data format (Data length) 7-1
