Parts Identification
Wood Components
(NOT TO SCALE)
B3 - POST - W4L11178
3"x3
"x70 3/8" (76x76x1786)
(1)
B4 - POST - W4L11179
3"x3"x70 3/8" (76x76x1786)
(1)
B5 - POST - W4L11180
3"x3"x59" (76x76x1500)
(1)
E4 - UPRIGHT - W4L11181
1 3/
8"x3 3/8"x70 3/8" (36x86x1786)
(1)
E5 - UPRIGHT - W4L11182
1 3/8"x3 3/8"x70 3/8" (36x86x1786)
(1)
E6 - UPRIGHT - W4L11183
1 3/8"x3 3/8"x41" (36x86x1040)
(2)
E7 - UPRIGHT - W4L11184
1 3/8"x3 3/8"x41" (36x86x1040)
(2)
F1 - UPRIGHT - W4L11185
1 3/
8"x2 3/8"x37" (36x60x940)
(2)
B1 - SWING BEAM - W4L09091
3"x3
"x89 1/2" (76x76x2274)
(1)
B2 - SWING BEAM - W4L09090
3"x3"x89 1/2" (76x76x2274)
(1)
E1 - FLOOR SUPPORT - W4L09077
1 3/
8"x3 3/8"x92" (36x86x2336)
(1)
E2 - LADDER RAIL - W4L09100
1 3/8"x3 3/8"x89 1/4" (36x86x2266)
(2)
E3 - BRACE - W4L09103
1 3/
8"x3 3/8"x72 5/8" (36x86x1845)
(2)
E77 - LEFT UPRIGHT - W4L11414
1 3/8"x3 3/8"x64 3/8" (36x86x1634)
(1)
E78 - RIGHT UPRIGHT - W4L11415
1 3/
8"x3 3/8"x64 3/8" (36x86x1634)
(1)
B6 - POST - W2A02493
3"x3"x59" (76x76x1500)
(1)
