Page 28 of 59 BACTcontrol – User Manual – V0.4.4 microLAN b.v.
6.4 POWER SUPPLY
The power supply cable should be connected on the main power connection ( 5)
Operation voltage: 230V - 50Hz or 110V – 60Hz
Peak power consumption: <700W
It is recommended to protect the electrical supply with an
earth leakage circuit breaker
6.5 CHANGING/REPLACING FUSES
For protection of the electrical system three fuses (part nr. 06BACT001A269) are
installed in the BACTcontrol.
1. The main power fuse (Nr 7 left side BACTcontrol)
2. PCB fuses
The printed circuit board is protected with two fuses
