Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 10/30
MID_M2000_BA_MODBUS_02_1805
2.8 Output #3
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
69
Service
Output #3:
Full scale frequency [Hz]
0x00B2 UINT16
--
0x03, 0x04, 0x06,
0x10
70
Service
Output #3:
Flow alarm minimum [%]
0x00B3 UINT16
--
0x03, 0x04, 0x06,
0x10
71
Service
Output #3:
Flow alarm maximum [%]
0x00B4 UINT16
--
0x03, 0x04, 0x06,
0x10
72
Service
Output #3:
Output mode
0x00B5 UINT16
--
0x03, 0x04, 0x06,
0x10
73
Service
Output #3:
Hardware select
0x00B6 UINT16
--
0x03, 0x04, 0x06,
0x10
74
Service
Output #3:
Output operation
0x00B7 UINT16
--
0x03, 0x04, 0x06,
0x10
2.9 Output #4
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
75
Service
Output #4:
Flow alarm minimum [%]
0x00B8 UINT16
--
0x03, 0x04, 0x06,
0x10
76
Service
Output #4:
Flow alarm maximum [%]
0x00B9 UINT16
--
0x03, 0x04, 0x06,
0x10
77
Service
Output #4:
Output mode
0x00BA UINT16
--
0x03, 0x04, 0x06,
0x10
78
Service
Output #4:
Hardware select
0x00BB UINT16
--
0x03, 0x04, 0x06,
0x10
79
Service
Output #4:
Output operation
0x00BC UINT16
--
0x03, 0x04, 0x06,
0x10

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
