Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 11/30
MID_M2000_BA_MODBUS_02_1805
2.10 Port A diagnostic counters
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
80
Firmware
Port A:
Packets processed
0x00BD UINT16 Read only 0x03, 0x04
81
Firmware
Port A:
Bradcast packets
0x00BE UINT16 Read only 0x03, 0x04
82
Firmware
Port A:
CRC errors
0x00BF UINT16 Read only 0x03, 0x04
83
Firmware
Port A:
Packets received
0x00C0 UINT16 Read only 0x03, 0x04
84
Firmware
Port A:
Packets sent
0x00C1 UINT16 Read only 0x03, 0x04
85
Firmware
Port A:
Parity errors
0x00C2 UINT16 Read only 0x03, 0x04
86
Firmware
Port A:
Framing errors
0x00C3 UINT16 Read only 0x03, 0x04
87
Firmware
Port A:
Overrun errors
0x00C4 UINT16 Read only 0x03, 0x04
88
Firmware
Port A:
Break detects
0x00C5 UINT16 Read only 0x03, 0x04
2.11 Port B diagnostic counters
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
90
Firmware
Port B:
Packets processed
0x00C6 UINT16 Read only 0x03, 0x04
90
Firmware
Port B:
Bradcast packets
0x00C7 UINT16 Read only 0x03, 0x04
91
Firmware
Port B:
CRC errors
0x00C8 UINT16 Read only 0x03, 0x04
92
Firmware
Port B:
Packets received
0x00C9 UINT16 Read only 0x03, 0x04
93
Firmware
Port B:
Packets sent
0x00CA UINT16 Read only 0x03, 0x04
94
Firmware
Port B:
Parity errors
0x00CB UINT16 Read only 0x03, 0x04
95
Firmware
Port B:
Framing errors
0x00CC UINT16 Read only 0x03, 0x04
96
Firmware
Port B:
Overrun errors
0x00CD UINT16 Read only 0x03, 0x04
97
Firmware
Port B:
Break detects
0x00CE UINT16 Read only 0x03, 0x04
