Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 12/30
MID_M2000_BA_MODBUS_02_1805
2.12 Measurements
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
98
Firmware
T1/T+[m
3
]
0x00CF
FLOAT32
Read only 0x03, 0x04
99
Firmware
T1/T+ [User units]
0x00D3
FLOAT32
Read only 0x03, 0x04
100
Firmware
T1/T+ Display string
0x0137
UCHAR16[8]
Read only
0x03, 0x04
101
Firmware
T2/T- [m
3
]
0x00D7
FLOAT32
Read only 0x03, 0x04
102
Firmware
T2/T- [User units]
0x00DB
FLOAT32
Read only 0x03, 0x04
103
Firmware
T2/T- Display string
0x013F
UCHAR16[8]
Read only
0x03, 0x04
104
Firmware
T3/TN [m
3
]
0x00DF
FLOAT32
Read only 0x03, 0x04
105
Firmware
T3/TN [User units]
0x00E3
FLOAT32
Read only 0x03, 0x04
106
Firmware
T3/TN Display string
0x0147
UCHAR16[8]
Read only
0x03, 0x04
107
Firmware
T1/T+ Rollover
counter
0x00E7 UINT16 Read only 0x03, 0x04
108
Firmware
T2/T- Rollover
counter
0x00E8 UINT16 Read only 0x03, 0x04
109
Firmware
Flow velocity [m/s]
0x00E9
FLOAT32
Read only 0x03, 0x04
110
Firmware
Flow rate [m
3
/s]
0x00ED
FLOAT32
Read only 0x03, 0x04
111
Firmware
Flow rate [User units]
0x00F1
FLOAT32
Read only 0x03, 0x04
112
Firmware
Relative flow rate [%]
0x00F3
FLOAT32
Read only 0x03, 0x04
113
Firmware
Preset batch
totalizer [m
3
]
0x00EB
FLOAT32
Read only 0x03, 0x04
114
Firmware
Preset batch totalizer
[User units]
0x00EF
FLOAT32
Read only 0x03, 0x04
115
Firmware
Flow direction
0 = no flow
1 = forward
2 = reverse
0x012D
UINT16
Read only
0x03, 0x04
