Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 13/30
MID_M2000_BA_MODBUS_02_1805
2.13 Meter diagnostic counters
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
116
Firmware Power up counter 0x00F5
UINT16
Read only 0x03, 0x04
117
Firmware Detector error counter 0x00F6
UINT16
Read only 0x03, 0x04
118
Firmware Empty pipe counter 0x00F7
UINT16
Read only 0x03, 0x04
119
Firmware Full scale counter 0x00F8
UINT16
Read only 0x03, 0x04
120
Firmware
Totalizer overflow
counter
0x00F9
UINT16
Read only 0x03, 0x04
121 --
Reserved 0x00FA
UINT16
Read only 0x03, 0x04
122 --
Reserved 0x00FB
UINT16
Read only 0x03, 0x04
123
Firmware Pulse sync counter 0x00FC
UINT16
Read only 0x03, 0x04
124
Firmware ADC Interrupt counter 0x00FD
UINT16
Read only 0x03, 0x04
125
Firmware ADC range counter 0x00FE
UINT16
Read only 0x03, 0x04
126
Firmware WDT resets counter 0x00FF
UINT16
Read only 0x03, 0x04
127
Firmware WDT location 0x0100
UINT16
Read only 0x03, 0x04
128
Firmware System error # 0x0101
UINT16
Read only 0x03, 0x04
129
Firmware Token error counter 0x0102
UINT16
Read only 0x03, 0x04
130 --
Reserved 0x0103
UINT16
Read only 0x03, 0x04
131 --
Reserved 0x0104
UINT16
Read only 0x03, 0x04
132 --
Reserved 0x0105
UINT16
Read only 0x03, 0x04
133
Firmware
Meter status (see
below)
0x0106 UINT16 Read only 0x03, 0x04
134
Firmware
Action request
overflows
0x0109
UINT16
Read only 0x03, 0x04
135
Firmware
Measurement
overflows
0x010A
UINT16
Read only 0x03, 0x04
136
Firmware Remote resets 0x0154
UINT16
Read only 0x03, 0x04
Additional information to No. 133 meter status (register 0x0106)
Bit no.
Description
Bit no.
Description
BIT 0
Detector Error
BIT 8
ADC Range Error
BIT 1
Empty Pipe Error
BIT 9
Reserved
BIT 2
Full Scale Flow Error
BIT 10
Reserved
BIT 3
Totalizer Rollover Error
BIT 11
Reserved
BIT 4
Totalizer Rollover Status
BIT 12
Token Error
BIT 5
Flow Simulation Status
BIT 13
Unused
BIT 6
Pulse Synchronization Warning
BIT 14
Unused
BIT 7
ADC Interrupt Error
BIT 15
Unused
