Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 9/30
MID_M2000_BA_MODBUS_02_1805
2.6 Output #1
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
55
Service
Output #1:
Pulses per unit [m
3
]
0x0098 FLOAT32
--
0x03, 0x04, 0x10
56
Service
Output #1:
Pulses per unit [User units]
0x009C FLOAT32
--
0x03, 0x04, 0x10
57
Service
Output #1:
Pulses width [ms]
0x00A0 UINT16
--
0x03, 0x04, 0x06,
0x10
58
Service
Output #1:
Flow alarm minimum [%]
0x00A1 UINT16
--
0x03, 0x04, 0x06,
0x10
59
Service
Output #1:
Flow alarm maximum [%]
0x00A2 UINT16
--
0x03, 0x04, 0x06,
0x10
60
Service
Output #1:
Output mode
0x00A3 UINT16
--
0x03, 0x04, 0x06,
0x10
61
Service
Output #1:
Ouput operation
0x00A4 UINT16
--
0x03, 0x04, 0x06,
0x10
2.7 Output #2
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
62
Service
Output #2:
Pulses per unit [m
3
]
0x00A5 FLOAT32
--
0x03, 0x04, 0x10
63
Service
Output #2:
Pulses per unit [User units]
0x00A9 FLOAT32
--
0x03, 0x04, 0x10
64
Service
Output #2:
Pulses width [ms]
0x00AD UINT16
--
0x03, 0x04, 0x06,
0x10
65
Service
Output #2:
Flow alarm minimum [%]
0x00AE UINT16
--
0x03, 0x04, 0x06,
0x10
66
Service
Output #2:
Flow alarm maximum [%]
0x00AF UINT16
--
0x03, 0x04, 0x06,
0x10
67
Service
Output #2:
Output mode
0x00B0 UINT16
--
0x03, 0x04, 0x06,
0x10
68
Service
Output #2:
Ouput operation
0x00B1 UINT16
--
0x03, 0x04, 0x06,
0x10

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
