Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 7/30
MID_M2000_BA_MODBUS_02_1805
2.2 Meter calibration
2.3 Meter measurement settings
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
31
User Flow unit 0x0083 UINT16
--
0x03, 0x04,
0x06, 0x10
32
User
Volume unit 0x0084 UINT16
--
0x03, 0x04,
0x06, 0x10
33
User
Unit multiplier 0x0085 UINT16
--
0x03, 0x04,
0x06, 0x10
34
User
Zero scale flow [User
units]
0x010D FLOAT32
--
0x03, 0x04,
0x10
35
User
Full scale velocity [m/s] 0x0086 FLOAT32
--
0x03, 0x04,
0x10
36
User
Full scale flow [User units] 0x0090 FLOAT32
--
0x03, 0x04,
0x10
37
User
Low flow cutoff [%] 0x008E FLOAT32
--
0x03, 0x04,
0x10
38
User
Flow direction 0x0092 UINT16
--
0x03, 0x04,
0x06, 0x10
39
User
Damping factor [s] 0x0093 UINT16
--
0x03, 0x04,
0x06, 0x10
No
.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
18
Admin
Detector diameter
0x006F UINT16
--
0x03, 0x04,
0x06, 0x10
19
Admin
Detector diameter
Other [mm]
0x0070 UINT16
--
0x03, 0x04,
0x06, 0x10
20
Admin
Detector factor
0x0071 FLOAT32
--
0x03, 0x04,
0x10
21
Firmware
[Factory]
Detector factor
0x0073 FLOAT32 Read only 0x03, 0x04
22
Admin
Detector offset [m/s]
0x0075 FLOAT32
--
0x03, 0x04,
0x10
23
Firmware
[Factory]
Detector offset
0x0077 FLOAT32 Read only 0x03, 0x04
24
Admin
Amplifier factor
0x0079 FLOAT32
--
0x03, 0x04,
0x10
25
Firmware
[Factory]
Amplifier factor
0x007B FLOAT32 Read only 0x03, 0x04
26
Admin
Detector current [mA]
0x007D FLOAT32
--
0x03, 0x04,
0x10
27
Firmware
[Factory]
Detector current [mA]
0x007F FLOAT32 Read only 0x03, 0x04
28
Service
Power line frequency [Hz]
0x0081 UINT16
--
0x03, 0x04,
0x06, 0x10
29
Admin
Excitation frequency [Hz]
0x0082 UINT16
--
0x03, 0x04,
0x06, 0x10
30
Service
Scale factor [%]
0x010B FLOAT32
--
0x03, 0x04,
0x10
