Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 8/30
MID_M2000_BA_MODBUS_02_1805
2.4 Digital input
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
40
Service
Digital input:
Input operation
0x0094 UINT16
--
0x03, 0x04, 0x06,
0x10
41
Firmware
Digital input: Status 0x0155 UINT16
Read only
0x03; 0x04
2.5 Analog output
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC
support
42
Service Analog output range 0x0095 UINT16
--
0x03, 0x04,
0x06, 0x10
43
Firmware
Analog output offset 0x0096 FLOAT32
Read only
0x03; 0x04
44
Admin
Analog output calibration
point A [A]
0x0126 FLOAT32
--
0x03, 0x04,
0x10
45
Admin
Analog output calibration
point B [A]
0x0128 FLOAT32
--
0x03, 0x04,
0x10
46
Firmware
[FACTORY] Analog output:
Calibration point A [A]
0x0088 FLOAT32
Read only
0x03; 0x04
47
Firmware
[FACTORY] Analog output:
Calibration point B [A]
0x008C FLOAT32
Read only
0x03; 0x04
48
Firmware
Analog output slope 0x0131 FLOAT32
Read only
0x03; 0x04
49
Service
Analog customer offset
4 mA [A]
0x0133 FLOAT32
--
0x03, 0x04,
0x10
50
Service
Analog customer offset
20 mA [A]
0x0135 FLOAT32
--
0x03, 0x04,
0x10
51
Firmware
Analog output current [A] 0x014E FLOAT32
Read only
0x03; 0x04
52
Firmware
Analog output current string
[mA]
0x0150 FLOAT32
Read only
0x03; 0x04
53
Service
Alarm mode 0x012E UINT16
0x03, 0x04,
0x06, 0x10
54
None
Fixed current mode 0x008A FLOAT32
Port B
0x03, 0x04,
0x10

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
