Badger Meter ModMAG M2000 User Manual

Memory maps by category Page 14/30
MID_M2000_BA_MODBUS_02_1805
2.14 Miscellaneaous
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
137
Firmwar
e
Power loss totalizer
[seconds]
0x0107
UINT16
--
0x03, 0x04
138
User Display backlights mode 0x010F
UINT16
--
0x03, 0x04, 0x06,
0x10
139
Service Preset batch amount [m
3
] 0x0110
FLOAT32
--
0x03, 0x04
140
Admin Menu reset allowed 0x0112
UINT16
--
0x03, 0x04, 0x06,
0x10
141
User Menu language setting 0x0114
UINT16
--
0x03, 0x04, 0x06,
0x10
142
User
File System -
Number of records to read
0x0117
UINT16
--
0x03, 0x04, 0x06,
0x10
143
None Configuration status 0x011D
UINT16
Port B
0x03, 0x04, 0x06,
0x10
144
None Port B extended address 0x0118
UINT16
Port B
0x03, 0x04, 0x06,
0x10
2.15 Verification tool support
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
145
Firmware
Analog input
measure value
0x0115
FLOAT32
Read
only
0x03, 0x04
146
Admin
Analog input
measure counter
0x0119
UINT16
--
0x03, 0x04, 0x06,
0x10
147
Firmware
Empty pipe actual
Resistance [ohms]
0x011A
FLOAT32
Read
only
0x03, 0x04
2.16 Empty pipe
No.
Write
security
Register name
Register
address
Register
Type
Read /
Write
FNC support
148
Admin
Empty pipe
calibration [volts]
0x011E
FLOAT32
--
0x03, 0x04, 0x10
149
Firmware
Empty pipe
measure value [volts]
0x0120
FLOAT32
Read only 0x03, 0x04
150
Admin
Full pipe
calibration [volts]
0x0122
FLOAT32
--
0x03, 0x04, 0x10
151
Service Empty pipe mode 0x0124
UINT16
--
0x03, 0x04, 0x06,
0x10
