Motorized Linear Actuator baelz 373-E07
4. ASSEMBLY
Make sure that the specications on the nameplate correspond to those in
the order documents!
4.1 Fitting position
Whenttingwiththeconnectingrodinhorizontalposition,tthelinearactuatorsuchthatthe
sides of the yoke are positioned one above the other in the vertical plane.
● Allow for about 140 mm space above the cover at the site of installation.
● Checktheworkenvironmentbeforettingtheactuatorandputtingitintooperation:
● Make sure that the valve is correctly installed. For detailed information, refer to the
valve's installation instructions.
● Determine the mounting position of the linear actuator. Do not mount linear actuators
"headdown"belowthevalve.
Attention
Fig. 2: Fitting position
