Motorized Linear Actuator baelz 373-E07
2.3 Technical Specications
1)At60Hzthepositioningspeedandpowerconsumptionbothincreaseby20%.
2)Othersupplyvoltagesavailableuponrequest.CongurationoptionsareindicatedintheBaelzpricelist.
Table 2. Technical Specifications, baelz 373-E07
E07-20-06-S21/L E07-20-18-S21/L E07-07-130-S21/L
Actuating force N
2000 2000 700
Positioning speed
1)
mm/min
6 18 130
Supply voltage
2)
24V/115V/230V50/60Hz±10%
Power consumption (230 V) VA
11.7
Operating mode acc. to IEC 34-1
S1-100%
Type of motor
synchronous motor (syn)
Motor protection
stall-proof motor (B))
Maximum stroke mm
44
Cable glands
3x M20 x 1,5
Electrical connection
internal terminal block, see wiring diagram for terminal allocation
Limit switches
2 load-dependent limit switches,
max. 250 V AC, max. 6 A
Fitting position
asrequired,butnot"headdown"withtheactuatorbelowthevalve
Ambient temperature °C
0 to +50
Position indicator
position of spindle coupling relative to indicator marks on yoke
Manual adjustment
with (yellow) release button and manual adjuster
IP-rating according to EN 60529
IP 42
Trapezoidal thread
Tr 10 x 3
Connection type
yoke S21 / S21-L
Weight, approx. kg
2,2

Baelz Automatic 373-E07 Specifications

General

Brand	Baelz Automatic
Model	373-E07
Category	Controller
Language	English
