Motorized Linear Actuator baelz 373-E07
7.5.3 Meaning of LED signals
red LED
green LED
LED
signal
LED
signal
Meaning
1
greeno󰀨
red o󰀨
Unitisswitchedo󰀨.
2
greeno󰀨
red on
Initialization run in progress.
3
green
ashing
redo󰀨
Unit is not initialized. Potentiometer in ideal position for initialization run (between 7.5 and
17.5%).
4
green
ashing
red on
Unit is not initialized. Potentiometer not in ideal position for initialization run.
Initialization still possible.
(IftheredLEDisickering,thepositionofthepotentiometerisattheedgeoftheoptimalrangeandthereforeOK.)
5
green
and red
ashing
Errorduringinitialization.Unitisnotinitialized.TheashingredLEDshowsthenumberof
theerrorcode:3ashes,interval,3ashes,interval→errorcode3.Seealsosection7.6.1.
6
green on
red o󰀨
Unit is initialized. No errors.
7
green on
red on
Immediately after the unit is switched on, both LEDs are lit for 2 seconds to show that they
are in working order.
8
green on
red
ashing
Unitisinitialized.DIP12setto1→errorafterinitializationrun,seesection7.6.1
DIP12setto0→errororalarmduringnormalpositioneroperation,seesection7.6.2.
