Motorized Linear Actuator baelz 373-E07
Table 3. Options and Extras, baelz 373-E07
Option / Extra Description Remarks
2EZ-V2
2 limit switches with position indicator
Mf-FgA
Multiturn potentiometer
А=200Ω,5kΩ,1kΩPleasespecify
resistance when ordering
2EZ-V2-FgA
2 limit switches with position indicator
and feedback potentiometer
7164-230
Built-in microprocessor controller
includingpotentiometer1-5kΩ
Supply:24V/115V/230V50/60Hz
order to match actuator!
7164-115
7064-24
7020-230
Digital positioner
Input / output signal:
0(2)...10 V / 0(4)...20mA
factory setting 0...10 V
Includes5kΩfeedbackpotentiometer
Supply:24V/115V/230V50/60Hz
7020-115
7020-24
MP373-E07-S21-L
Ständeraufbau für Armaturen mit
Spindel-Ø 16 mm
Surcharge on top of basic price of
373-E07...S21
MP373-E07-Silf
Silicone-free version
MP373-E07-KT9992
Mechanical travel limits
MP373-E07-RH
Locking manual override
MP373-E07-IP65
Ingress protection rating IP65
MP373-E07-2RC
2 additional RC snubbers Fitted in actuator E07..., 230 V
2.4 Options and Extras
2.5 Type name
baelz 373 - E07 - 20 - 18 - S21
motorized linear actuator actuator type thrust positioning speed yoke type
