3A-1. INSTRUMENT CLUSTER
11. Speedometer:
The speedometer indicates vehicle speed in km/h. Speedometer console has readings up to
100 km/h, but Max speed of vehicle is limited to 70 Km/h.
12. LCD display function: It has following readings
a. Odometer Reading :The odometer records the total distance, the vehicle has been driven.
b. Fuel indicator: This gives an approximate indication of the amount of fuel in the fuel tank. “F”
stands for full and “E” stands for empty.
c. Time : It shows the current time in 24 hour format.
d. Gear position indicator :It shows the current gear position in which the vehicle is running.
11
12
d
b
a
c
