www.baldormotion.com
8-12 Specifications MN1901
8.1.20 Pulse and direction input (X9)
All models Unit All models
Pulse and direction signals RS422
Input current (5V input) mA 1.2mA
Maximum input frequency MHz 1.25
Sampling interval ms Software selectable: 1, 2
8.1.21 Environmental
All models Unit
Operating temperature range °C °F
Minimum
Maximum
Derate
+0
+40
2.5% / °C between
40°C and 50°C (max)
+32
+104
2.5% / 1.8°F between
104°F and 122°F (max)
Storage temperature range -25to+70 -13to+158
Humidity % 10-90 non-condensing according to
DIN40 040 / IEC144
Above 31°C (87°F) derate linearly to
50% relative humidity at 40°C (104°F)
Maximum installation altitude
(above m.s.l.)
m
ft
1000
Derate 1.1% / 100m over 1000m
3300
Derate 1.1% / 330ft over 3300ft
Shock 10G according to
DIN IEC 68-2-6/29
Vibration 1G, 10-150Hz, according to
DIN IEC 68-2-6/29
