www.baldormotion.com
Accessories A-5MN1901
A.1.7 Feedback cable part numbers
A description of a Baldor feedback cable catalog number is shown here, using the example
number CBL025SF-R1:
Meaning Alternatives
CBL The item is a cable -
025 Indicates the length, in this example 2.5 meters
Various: see sections A.1.4 to
A.1.6.
SF ThecableisaServo motor Feedback cable -
R Resolver feedback cable with motor connector
E=Encoder / Hall feedback cable
D=EnDat / Hiperface feedback
cable
1
Drive connector included:
9-pin D-type connector (resolver)
15-pin D-type connector (Encoder/Hall &
EnDat/Hiperface)
-
Note: Feedback cables have the outer shield tied to the connector housing(s).
If you are not using a Baldor cable with your chosen feedback device, be sure to obtain a
cable that is a shielded twisted pair 0.34mm
2
(22 AWG) wire minimum, with an overall shield.
Ideally, the cable should not exceed 30.5m (100ft) in length. Maximum wire-to-wire or
wire-to-shield capacitance is 50pF per 300mm (1ft) length, to a maximum of 5000pF for 30.5m
(100ft).
