www.baldormotion.com
Input / Output 4-3MN1901
AIN0
(ADC.0)
X3
AIN0
(ADC.0)
1
2
3
X3
AIN0-
Differential c onnection Single ended connection
AIN0+
1
2
3
AIN0+
GND
Figure 25 - AIN0 analog input wiring
AIN0
1kΩ, 0.25W
potentiometer
(ADC.0)2
1
X3
1.5kΩ, 0.25W
0V
+24VDC
3
Figure 26 - Typical input circuit to provide 0-10V (approx.) input from a 24V source
