Balluff BNI00E7 User Manual
4
of 1
of 1 rating
42 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
www.balluff.com
35
10
Technical data
Electrical data
Voltage supply
18…30.2 V DC, per EN 61131
-2
Ripple
< 1%
Current consumption without load (US)
200 mA @ 24V
Maximum load current (UA)
9 A (total)
Input type PNP/NPN
EN 61131-2, type 3
Output type PNP/NPN
EN 61131-2
Load current per PNP/NPN output
(Pin 2)/(Pin 4)
max. 2 A
Load current Pin 1
max. 1.3 A (temperature-dependent)
CC
-
Link IE Field
Basic
Technology
Ethernet
Connection
M12, D-coded
Cable type
IEE
E 8
02.3
100
Bas
e-T
and
A
NSI
/TIA
/EI
A-
568
-B
(Ca
tego
ry 5
e)
4 pa
irs
of
shie
lded
cabl
e. D
oub
le-s
hie
lded
ca
ble
rec
omme
nded
.
Data transfer rate
100 Mbps
Max. cable length between stations
Up to 100 m
37
39
Table of Contents
Default Chapter
3
Table of Contents
3
1 General
5
Structure of the Guide
5
Typographical Conventions
5
Enumerations
5
Actions
5
Syntax
5
Cross-References
5
Symbols
5
Abbreviations
5
Deviating Views
5
2 Safety
6
Intended Use
6
Installation and Startup
6
General Safety Notes
6
Resistance to Aggressive Substances
6
Dangerous Voltage
6
3 First Steps
7
Module Overview
7
Port
8
Mechanical Connection
8
Electrical Connection
8
Supply Voltage
8
Function Ground
9
CC-Link IE Field Basic Connection
9
Sensor/Actuator Connection
9
4 Display
10
General
10
Factory Setting
10
Control and Display
10
Start-Up
10
Main Menu
11
Menu Point: Network Config
11
Menu Point: Module Info
11
Menu Point: Number of Occupied Stations
12
Menu Point: Factory Settings
12
5 Integration
13
General
13
Network Parameters
13
Network Configuration Settings
14
CSP+-File (Network Configuration Settings)
15
6 CC-Link IE Field Basic
16
General
16
CC-Link IE Field Basic Network
16
Ethernet
16
CIB Module
16
Pin-Port Numbering and Addressing
17
State Machine
18
7 Cyclical Transmission
19
General
19
RX and RY
19
Details
21
Word Range Rwr and Rww
22
Details: Module Status Area
24
Process Data Representation (Byte Swap)
24
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Balluff BNI00E7 and is the answer not in the manual?
Ask a question
