11.1 Accuracy
The specifications are typical values for BTL7-A/C/E/G... at
24VDC and room temperature, with a nominal length of
500mm in conjunction with the BTL-P-1013-4R,
BTL-P-1013-4S, BTL-P-1012-4R or BTL-P-1014-2R
magnet.
The BTL is fully operational immediately, with full accuracy
after warm-up.
For special versions, other technical data may
apply.
Special versions are indicated by the suffix -SA
on the part label.
Repeat accuracy
Voltage, typical
Current, typical
±10µm
±5µm
Sampling rate
Dependent on nominal length
At nominal length 500mm
250 µs to 5.7 ms
500 µs
Non-linearity at
Nominal length d500mm
Nominal length >500 to
d5500mm
Nominal length >5500mm
±50µm
±0.01% FS
±0.02% FS
Temperature coefficient
1)
d30ppm/K
Max. detectable speed 10m/s
11.2 Ambient conditions
2)
Operating temperature 40°C to +85°C
Operating temperature for UL
(only BTL-…-KA…)
max. +80°C
Storage temperature 40°C to +100°C
Relative humidity <90%, non-con-
densing
Rod pressure rating
(when installed in hydraulic
cylinders)
For Ø8mm
<250bar
For Ø10.2mm
<600bar
Shock rating
per EN60068-2-27
3)
150g/6ms
Continuous shock
per EN60068-2-29
3)
150g/2ms
Vibration
per EN 60068-2-6
3)
(note resonant frequency of
therod)
20g, 10 to 2000Hz
Degree of protection per
IEC60529
Connector (when attached) IP67
Cable IP68
3)
11.3 Supply voltage (external)
Voltage, stabilized
4)
:
BTL7-_1_ _-...
BTL7-_5_ _-...
20 to 28VDC
10 to 30VDC
Ripple d0.5V
ss
Current draw (at24VDC) d150mA
Inrush current d500mA/10ms
Reverse polarity protection
5)
Up to 36V
Overvoltage protection Up to 36V
Dielectric strength
(GND to housing)
500VAC
11.4 Output
BTL7-A… Output voltage
Load current
0 to 10V and 10 to 0V
d5 mA
BTL7-C… Output current
Load resistance
0 to 20mA / 20 to 0mA
d500 ohms
BTL7-E… Output current
Load resistance
4 to 20mA / 20 to 4mA
d500 ohms
BTL7-G… Output voltage
Load current
10 to 10V and 10to10V
d5 mA
Short circuit resistance Signal cable to 36 V
Signal cable to GND
11.5 Input
Programming inputs La, Lb: High-active
BTL7-_1_ _-...
BTL7-_5_ _-...
20 to 28VDC
10 to 30VDC
Overvoltage protection up to 36 V
1)
Nominal length = 500mm, magnet in the middle of the measuring range
2)
For
: Use in enclosed spaces and up to a height of 2000 m above sea
level.
3)
Individual specifications as per Balluff factory standard
4)
For
: The transducer must be externally connected via a limitedenergy
circuit as defined in UL 61010-1, a low-power source as defined in
UL60950-1, or a class 2 power supply as defined in UL 1310 or
UL1585.
5)
A prerequisite is that no current can flow between GND and 0 V in the
event of polarity reversal.
11
Technical data
BTL7-A/C/E/G_ _ _-M_ _ _ _-A/B/Y/Z(8)-S32/S115/S135/S140/KA_ _/FA_ _
Micropulse Transducer - Rod Style

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
