Balluff BTL7 Series Manual

24 english
11.6 Dimensions, weights
Diameter of rod 8mm or 10.2mm
Nominal length
For Ø8mm 25 to 1016mm
For Ø10.2mm 25 to 7620mm
Weight (depends on
length)
Approx. 2kg/m
Housing material Anodized aluminum
Rod material Stainless steel 1.4571
Rod wall thickness
For Ø8mm 0.9mm
For Ø10.2mm 2mm
Young's modulus Approx. 200kN/mm
2
Housing mounting via
threads
M18×1.5 or 3/4"-16UNF
Tightening torque Max.100Nm
BTL7-...-KA__
Cable material PUR
cULus20549
80°C, 300V,
internal wiring
Cable temperature –40°C to +90°C
Cable diameter Max. 7mm
Permissible bending
radius
Fixed routing ≥35mm
Movable ≥105mm
BTL7-...-FA__
Cable material PTFE
No UL approval available
Cable temperature –55°C to +200°C
Cable diameter Max. 7mm
Permissible bending
radius
Fixed routing ≥35mm
Movable No permissible bending
radius
11
Technical data (continued)
BTL7-A/C/E/G_ _ _-M_ _ _ _-A/B/Y/Z(8)-S32/S115/S135/S140/KA_ _/FA_ _
Micropulse Transducer - Rod Style

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
