Balluff BTL7 Series User Manual

4 english
BTL7-A/C/E/G5 __ -M ____ -K(8)-SR32/SR115/___
Micropulse Transducer - Rod Style
11
Accessories 22
11.1 Magnets 22
11.2 Connectors and cables 23
11.2.1 BKS-S32/S33M-00, freely configurable 23
11.2.2 BKS-S232/S233-PU-_ _, preassembled 23
11.2.3 BKS-S115/S116-PU-_ _, preassembled 24
11.3 Calibration box 24
12
Type code breakdown 25
13
Appendix 26
13.1 Converting units of length 26
13.2 Part label 26

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
