Balluff BTL7 Series User Manual

www.balluff.com 3english
BTL7-A/C/E/G5 __ -M ____ -K(8)-SR32/SR115/___
Micropulse Transducer - Rod Style
1
Notes to the user 5
1.1 Validity 5
1.2 Symbols and conventions 5
1.3 Scope of delivery 5
1.4 Approvals and markings 5
2
Safety 6
2.1 Intended use 6
2.2 General safety notes for the linear encoder 6
2.3 Explanation of the warnings 6
2.4 Disposal 6
3
Construction and function 7
3.1 Construction 7
3.2 Function 7
4
Installation and connection 8
4.1 Installation guidelines 8
4.2 Preparing for installation 8
4.3 Installing the transducer 9
4.3.1 Installation recommendation for hydraulic cylinders 9
4.4 Electrical connection 10
4.4.1 Connector SR32 10
4.4.2 Connector SR115 10
4.4.3 Cable connection 11
4.5 Shielding and cable routing 11
5
Startup 12
5.1 Starting up the system 12
5.2 Operating notes 12
6
Calibration procedure 13
6.1 Programming inputs 13
6.2 Calibration procedure notes 13
6.3 Calibration procedure overview 14
6.3.1 Teach-in 14
6.3.2 Adjusting 15
6.3.3 Reset 15
7
Teach-in 16
8
Adjusting 17
9
Resetting all values (reset) 19
10
Technical data 20
10.1 Accuracy 20
10.2 Ambient conditions
2)
20
10.3 Supply voltage (external) 20
10.4 Output 20
10.5 Input 20
10.6 Dimensions, weights 21

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
