5.1.2 Speed settings
The speed can be output in various units, which are
selected in attribute25 Velocity Format.
The settings of various other attributes relate to
the selected unit. It is recommended that the
required unit is set first, and then the dependent
attributes.
The speed is detected with a resolution of 0.1mm/s and
processed with an accuracy of 32bits. The preset unit for
the speed according to CIP is the standard unit for the
position (Counts = 1μm) per second, therefore 1μm/s.
This unit is below the measurement resolution of the speed
and therefore has a minimum increment of 100. The
resolution in which the speed data is output can be set
using attribute25 Velocity Format.
Attribute24:
Speed (Velocity Value)
This is the current value of speed, depending on the
attributes25 and 26. The value is identical to the value that
may be transmitted in the I/O Assembly Object.
Attribute25:
Speed unit (Velocity Format)
The unit of speed is found in this attribute and influences
attribute26 Velocity Resolution. Therefore attribute25
should be set first, before attribute26 is changed.
The internal measurement resolution for the
speed is at 100μm/s. This means that the unit
of steps per second (cps) is below this
resolution and the smallest increment is
100cps.
Possible units are listed in Tab. 5-2.
5
Configuration and parameterization (continued)
Designation Abbre-
viation
Identification
(Dec.)
Identification
(Hex.)
Steps
(counts) per
second
cps 7940 0x1F04
Meters per
second
m/s 11008 0x2B00
Centimeters
per second
cm/s 11009 0x2B01
Kilometers
per hour
km/h 11010 0x2B02
Feet per
second
ft/s 11014 0x2B06
Inches per
second
in/s 11015 0x2B07
Tab. 5-2: Speed units
Attribute26:
Speed resolution (Velocity Resolution)
The speed resolution specifies the smallest increment
in the selected speed format in which the speed value
is output. This parameter is identical to the
Velocity_Resolution entry in the Config Assembly
(see5.3.8 Velocity_Resolution on page16).
If Config_assemby_parameter_recognition is activated,
this parameter is ignored.
BTL7-V50D-…
Configuration Manual
