MODEL 20XP HYDRAULIC COMPONENTS
** Hydraulic components, ttings, hoses will very depending on
optional equipment. Order by physical description.
** Hydraulic pumps, track motors, and valve banks need to be ordered by serial number of machine.
Make sure to order components according to tting type, ttings may vary on all components.NOTICE
TRAILERIZED MACHINE
LOCATION PART NUMBER DESCRIPTION
1. See Page 114 - 115 Hydraulic Tank
2. a. 900-3932-95 In-Tank Filter Assembly
b. 900-3931-34 Filter Element Only
3. a. 900-3925-21 Suction Screen - 1 1/2”
b. 900-3932-07 Ball Valve - 1 1/2”
4. ** Pump
5. See Page 106 Relief Block
6. 900-3924-55 Variable Speed Flow Control Valve
7. See Page 95 Reversing “Autofeed Plus”
8. 900-3906-29 Top Feedwheel Motor
9. 900-3906-29 Bottom Feedwheel Motor
10. 900-3981-95 3 Section Valve Bank
11. 900-3928-16 Flipper Cylinder
12. 900-3921-57 Swivel Discharge Hydraulic Motor
13. a. 900-3925-07 Yoke Lift Cylinder - Welded
b. 904-0007-14 Pin For Welded Cylinder (Not Shown)
c. 904-0006-90 Seal Kit - Welded Lift Cylinder (Not Shown)
14. 900-3902-08 2 Section Valve Bank
15. 900-3949-09 Check Valve
16. 900-3934-24 Rear Stabilizer Cylinder
17. 900-3934-24 Tongue Jack Cylinder
18. 900-3920-01 Tongue Jack Valve
