Bandit 20XP - Page 110

Bandit
106
Copyright 12/17
MODEL 20XP
Parts may not be exactly as shown.NOTICE
HYDRAULIC COMPONENTS
MAIN RELIEF BLOCK
LOCATION PART NUMBER DESCRIPTION
Hydraulic Hose To Tank
Hydraulic Hose From Pump
1. 900-3928-06 Plug for Main Relief Only
2. 900-3919-96 Main Relief Only
3. 900-3977-40 Main Relief Block
4. 500-0000-73 Main Relief Block Assembly (Includes 1 - 3)
T
P
2
1
3
