MODEL 20XP MAINTENANCE
5 & 6 Lug Hubs (1/2” - 20 Studs) ........................ 90 - 120 ft.-lbs. Torque (122 - 163 Nm)
8 Lug Hubs (1/2” - 20 Studs) .............................. 90 - 120 ft.-lbs. Torque (122 - 163 Nm)
8 Lug Hubs (9/16” - 18 Studs) ............................ 110 - 120 ft.-lbs. Torque (149 - 163 Nm)
8 Lug Hubs (5/8” - 18 Studs) .............................. 190 - 210 ft.-lbs. Torque (258 - 285 Nm) (Cone Nut)
8 Lug Hubs (5/8” - 18 Studs) .............................. 275 - 325 ft.-lbs. Torque (373 - 441 Nm) (Flange Nut)
8 Lug Hubs (22mm x 1.5 Studs) ......................... 450 - 500 ft.-lbs. Torque (610 - 678 Nm) (Flange Nut)
10 Lug Hubs (3/4” - 16 Studs) ............................ 450 - 500 ft.-lbs. Torque (610 - 678 Nm)
(Consult axle manufacturers manual shipped with each machine for specic axle-stud-wheel combination lug nut torques.)
KEEP LUG NUTS PROPERLY TIGHTENED, CHECK NEW UNIT BEFORE OPERATION, CHECK
AGAIN AFTER 20-25 MILES (32-40 km) AND REGULARLY CHECK AT LEAST WEEKLY.
BASIC WHEEL TORQUE REQUIREMENTS (per mfg.)
BOLT TORQUE CHART
(THESE TORQUES ARE BASED ON DRY, CLEAN THREADS)
DESCRIPTION BOLT SIZE TORQUE (FT.-LBS.) TORQUE (Nm)
Chipper Bearing Mounting Bolts 3/4” - 10 NC 220 298
Drum Head Shaft Bushing “4040” 5/8” - 11 NC 142 193
Drum Head Shaft Bushing “5050” 7/8” - 9 NC 258 350
Anvil 1/2” - 13 NC 75 102
Double Edge Knife Bolts 5/8” - 18 NF 180 245
Babbitt Knife Bolts 5/8” - 18 NF 210 285
Knife Holder Bolts 3/4” - 10 NC 250 339
Feedwheel Bearing Bolts 5/8” - 11 NC 80 108
Feedwheel Bearing Set Screws 3/8” - 24 NF 20 27
Conveyor Bearings - Drive Wheel 5/8” - 11 NC 225 305
Conveyor Bearing Set Screws - Drive Wheel 3/8” - 24 NF 20 27
Conveyor Bearings - Idler Wheel 5/8” - 11 NC 80 108
Conveyor Bearing Set Screw - Idler Wheel 3/8” - 24 NF 20 27
Engine Hold Downs 5/8” - 11 NC 125 169
Engine Hold Downs 3/4” - 10 NC 350 475
“DT” Hydraulic Motor Shaft Nut 1 1/8” - 20 NEF 340 461
Engine Sheave Bushing “E” 1/2” - 13 NC 60 81
Engine Sheave Bushing “F” 9/16” - 12 NC 75 102
Chipper Sheave Bushing “F” 9/16” - 12 NC 75 102
Chipper Sheave Bushing “J” 5/8” - 11 NC 135 183
Chipper Sheave Bushing “M”
3/4” - 10 NC 225 305
Pump Sheave Bushing “2517”
1/2” - 13 NC 36 48
Feedwheel Motor Sprocket Bushing “Q2”
3/8” - 16 NC 30 41
Feedwheel Sprocket Bushing “R1”
3/8” - 16 NC 30 41
Autofeed Cartridge Nut
N/A 4 - 6 5 - 8
Autofeed Plus Solenoid Retainer Nut
N/A 4 - 6 5 - 8
Hitch Mount Bolts
5/8” - 11 NC 220 298
Before tightening bolts be sure you have the correct size bolt for the correct amount of torque.
Use only factory approved knives and hardware.
