Bandit
57Copyright 12/17
MODEL 20XP
Figure 1
Clean all the threaded
holes if the knife holder is
removed or replaced.
REMOVABLE KNIFE HOLDERS
MAINTENANCE
Figure 3
Install the knives and
torque the knife bolts to
210 ft.-lbs. (285 Nm)
1 235 4 6
Figure 2
Install knife holder,
apply Loctite 243 to
the knife holder bolts
and torque to 250
ft.-lbs. (339 Nm).
Knife Holder
1
3 2
5 4
67
9 8
