Bandit 20XP - Page 64

Bandit
60
Copyright 12/17
MODEL 20XP
ANVIL ADJUSTMENT
MAINTENANCE
View looking through the
feedwheels at the throat area
View looking up underneath
drum head and base area
Anvil Bolts
Torque To
Specs
Anvil Adjuster
Bolt
Anvil Puller
Block
Anvil Bolts
Torque To
Specs
Anvil Clamp
Plate
Anvil Adjuster
Bolt
Anvil Bolts
Torque To
Specs
Anvil
Knife
Drum Head
Anvil Adjuster
Bolts
Anvil Puller
Block
Anvil To
Knife Gauge
Anvil Clamp
Plate
Anvil
KnifeDrum Head
Anvil To
Knife Gauge
