Technical data
148 8LS...-3 user's manual V2.50
2.14.8.6 8LSA76/77/78...-3 - Dimensions
R20
51
(4x)
90$
190
(4x)15
215
16
80K0
M
190
28
k6
Detail A-Flansch Standardlagerung
detail A-flange increased bearing
Detail A-Flansch verstärktes A-Lager
detail A-flange increased bearing
DIN 6885-A10-8-70
k638
j6180
5
4
5
41
40
166,5
R
2
M12
28
DIN 6885-A12-8-100
4
5
k642
45
45
166,5
j6
M16
EnDat/Resolver feedback Extension of K
0
depending on motor option [mm]
Model number K
0
M Holding brake Heavy-duty
holding brake
Special brake Reinforced A-
side bearing
8LSA76.eennnffgg-3 311 279 37 54 50 10
8LSA77.eennnffgg-3 356 324 37 54 50 10
8LSA78.eennnffgg-3 401 369 37 54 50 10
IMPORTANT: Motor option "oil seal" has no effect on the motor length.
